NZXT H6 Flow RGB, Black, Compact Dual-Chamber Chassis w/ Tempered Glass, 3x 120mm RGB Fans, E-ATX/ATX/mATX/mITX - CC-H61FB-R1
EXPERIENCE PERFORMANCE WITH A FRESH PERSPECTIVE
The H6 Flow's innovative compact design emphasizes GPU cooling with a strategically angled front corner, so the fans direct air where it's most needed. The panoramic glass proudly showcases the interior, while the dual-chamber layout frees up space for a cleaner look and better cooling performance.
A SEAMLESS SHOWCASE
Tempered glass front and side panels offer an uninterrupted view of components, while the dual-chamber design hides PSU and storage for a sleek, compact, and standout look.
ANGLED AIRFLOW
The angled front-right corner with 3 x 120mm fans targets heat-prone components. Supports 2 x 140mm fans beneath the GPU for optimal cooling while perforated panels enhance airflow.
BUILDING MADE SIMPLE
H6 Flow's intuitive design makes building a breeze. Wide channels and included straps aid cable management. Tool-less access to top and side panels simplifies tinkering and upgrading.
| Core Chassis Specifications | |
|---|---|
| Case Edition | H6 Flow RGB |
| Case Form Factor | Dual Chamber Mid Tower |
| Motherboard Form Factor |
|
| I/O, Bays & Expansion | |
|---|---|
| Front/Side/Top Panel I/O |
|
| Drive Bays |
|
| Standard Expansion Slots | 7 |
| Vertical Expansion Slots | |
| Fans & Filters | |
|---|---|
| Fan Bays |
|
| Fans Included | 3 x 120mm w/ Addressable RGB LEDs |
| Fan Controller/Hub | |
| Dust Filters | |
| Liquid Cooling Support | |
|---|---|
| Front Radiator Compatibility | |
| Top Radiator Compatibility | 1 x 120/140/240/280/360mm |
| Bottom Radiator Compatibility | |
| Rear Radiator Compatibility | 1 x 120mm |
| Side Radiator Compatibility | |
| Clearances | |
|---|---|
| Max CPU Cooler Height | 163 mm |
| Max GPU Card Length | 365 mm |
| Cable Routing Space | 91 mm |
| Side Panels | |
|---|---|
| Window/s | Yes |
| Window Configuration |
|
| Window Construction | Tempered Glass |
| LED Lighting Functionality | |
|---|---|
| LED Lighting | Yes |
| LED Lighting Emitters | Included LED Fan/s |
| LED Lighting Colour | RGB |
| LED Lighting Support & Control | |
| Power Supply Compatibility | |
|---|---|
| PSU Included | No |
| PSU Wattage (If Included) | |
| PSU 80+ Rating (If Included) | |
| PSU Support | ATX |
| PSU Mounting Location | Top Mount, Rear |
| Max PSU Length | 200 mm |
| Chassis Physical Specifications | |
|---|---|
| Colour | Black |
| Chassis Construction Materials | SGCC |
| Dimensions | 287 x 435 x 415 (WxHxD mm) |
| Weight | 9.4 kg (Approx) |
| Part Number | CC-H61FB-R1 |
|---|---|
| EAN / UPC | 5056547204079 |
